3、主要技术参数：
| |
项目/item |
单位/unit |
ZK5232 |
ZK5263 |
工作台直径 Diameter. of the table |
mm |
Φ2,400 |
Φ4,800 |
最大加工直径Max. Diameter of the Work piece |
mm |
Φ3,250 |
Φ6,300 |
最大工件重量Max. Weight of the Work piece |
kg |
8,000 |
12,000 |
最大钻孔直径Max. Diameter of the Rollins |
mm |
Φ50 |
Φ50 |
单个钻头的最大金属切除率Max. Efficiency of single spindle |
cm3/min |
>300 |
>300 |
行程 Traverse paths |
|
|
|
X 轴：X-axis |
mm |
4,200 |
7,250 |
U 轴：U-axis |
mm |
2,200 |
3,725 |
Z 轴：Z-axis |
mm |
800 |
800 |
W轴：W-axis |
mm |
800 |
800 |
进给速度 Feed rates |
|
|
|
X 轴：X-axis |
mm/min |
8,000 |
8,000 |
U 轴：U-axis |
mm/min |
8,000 |
8,000 |
Z 轴：Z-axis |
mm/min |
10,000 |
10,000 |
W轴：W-axis |
mm/min |
10,000 |
10,000 |
C轴：C-axis |
rpm |
2 |
0.75 |
定位精度 Positioning accuracy |
|
|
|
X 轴：X-axis |
mm |
0.065/全长 |
0.095/全长 |
U 轴：U-axis |
mm |
0.045/全长 |
0.055/全长 |
Z 轴：Z-axis |
mm |
0.035/全长 |
0.035/全长 |
W轴：W-axis |
mm |
0.035/全长 |
0.035/全长 |
C轴：C-axis |
＂ |
±8 |
±8 |
重复定位精度Re-positioning accuracy |
|
|
|
X 轴：X-axis |
mm |
0.015 |
0.015 |
U 轴：U-axis |
mm |
0.015 |
0.015 |
Z 轴：Z-axis |
mm |
0.015 |
0.015 |
W轴：W-axis |
mm |
0.015 |
0.015 |
C轴：C-axis |
＂ |
3 |
3 |
主轴参数 Spindle date |
|
|
|
主轴规格Spindle type |
ISO |
BT50 |
BT50 |
主轴转速 Spindle rotation speed |
rpm |
6,000 |
6,000 |
主轴数量Number of the Spindle |
个 |
2 |
2 |
功率 Power |
|
|
|
主轴功率Power of Spindle |
KW |
22 |
22 |
机床总功率Total power |
KW |
95 |
95 |
数控系统CNC System |
|
FAGOR8055 |
FAGOR8055 |
其它 others |
|
|
|
机床外形尺寸(长×宽×高)Overall dimension (L×W×H) |
mm |
7,875×4,400×4,850 |
10,925×7,450×4,850 |
机床重量Total Weight of machine |
kg |
22,000 |
45,000 |
|
|
